Model M76 Installation

Please read complete instructions before beginning!

The Model M76 is designed for sinks with TWO water pipes on 8" centers. It can be installed either on the top of the sink deck or on the wall (see below). Both the standard 8-inch Wall Type Fittings and the standard 8-inch Deck Type Fittings are included (keep the fittings you do not use in case you change your type of sink later).

Recommended tools: pipe wrench; plumbers basin wrench (for removal of old faucet, available at most hardware stores); large screwdriver; pliers; towels; bucket.

Supplies: See notes for specific installation below; pipe compound; shut-off valves (if needed).
Wall Installation
Wall type sink installation
Water pipes come out through the wall.
Deck Installation
Deck type sink installation
Water pipes come up through top of sink.

DECK OR WALL INSTALLATION

  1. Turn off your Hot and Cold water lines under your sink. (If you do not have shut off valves under your sink, you must shut off your water at your pump or meter.)
  2. If you do not have shut-offs under your sink, we recommend you install them while making this installation.
  3. Remove your present water faucets from your sink.
  4. Install the Wall or Deck Type Fittings onto your sink and water pipes using the following instructions:

    5. DECK INSTALLATION ONLY

    Note: If the plumbing under your sink is 1/29 galvanized iron pipe it must be reduced to 3/89, 7/169 or 1/29 O.D. copper tubing. There are two types of standard fittings available at plumbing departments and shops for this conversion, if needed. Shown at the left is plain copper tubing with a friction washer and rubber seal. (Not shown - also available are flexible and rigid tubing with a ball or seal attached.)

    1. Place steel washers onto deck unions with crown side up.
    2. Place large black rubber washers over threads up under steel washers as shown.
    3. Put deck union bodies down through holes in sink.
    4. Screw plastic lock nuts onto deck union bodies under sink sink until they touch sink. DO NOT TIGHTEN.
    5. Connect the copper tube fittings onto bottom of deck union bodies. (It is optional whether you use the plastic tail piece nut furnished with our unions or brass nuts if part of your fittings).
    6. Flush water pipes of all chips and foreign matter by turning on the water momentarily, being careful not to spray water over your kitchen. Hold a pan or towel over the unions while performing this operation. Screens must NOT be in unions when flushing pipes.
    7. Push screens into top of unions with thumbs.
    8. Push O-rings into grooves on front of deck union heads with thumbs.

    WALL INSTALLATION ONLY

    Note: The Wall Fittings have a standard 1/29 pipe thread and screw directly onto your 1/29 galvanized water pipes. Use pipe compound on threads when making this connection.

    1. Place the steel washers over the shoulder of wall union bodies as shown with crown toward body.
    2. Screw the wall union bodies onto your 1/29 water pipes with a pipe wrench or channel lock pliers. Be sure you keep the steel washer over the shoulder of the body when tightening against wall. When thread tightens, adjust unions so they are 8 inches center to center and are horizontally straight with sink.
    3. Flush water pipes of all chips and foreign matter by turning on the water momentarily, being careful not to spray water over your kitchen. Hold a pan or towel over the unions while performing this operation. Screens must NOT be in unions when flushing pipes.
    4. Push screens into front of unions with thumbs.
    5. Push O-rings into grooves on front of unions with thumbs.

DECK OR WALL INSTALLATION

  1. Disassemble the handles, cover and tank as follows:
  2. Be sure O-rings and screens are in place in union heads, then connect the valve body onto the unions. DO NOT over tighten the union nuts. Finger tighten or very lightly snug with pliers only. DO NOT use wrench as O-ring seals are used.

    3. DECK INSTALLATION ONLY: Adjust complete assembly straight on sink and tighten plastic lock nuts (See "e" in Deck illustration above) under sink with pliers.

  3. Turn water on and check all connections for any possible leaks. If a leak appears at these connections, remove body and check for foreign matter under O-rings and tighten inserts in union nuts with a large screw driver being sure the nut swivels freely when insert is tight.
  4. Replace the detergent tank and reconnect the plastic tube.
  5. Now reassemble the cover, front panel and brass rings.
  6. Adjust position of handles on faucet stems to achieve correct pressure on valve seals.

    7. The handles are equipped with built-in stops to eliminate unnecessary pressure being put on the valve bib washers when closing the valves. When the handles are properly set, this stop will lengthen the life of your bib washers by many times.

    Set each handle separately:

    1. Using the handle, open the valve and close it slowly until the water flow stops. DO NOT CLOSE IT BEYOND THIS POINT.
    2. Pull out the handle to remove it from the valve stem.
    3. Replace the handle on valve stem with the lever next to the stop as shown.
    4. You will note that the end of the valve stem is serrated or notched. Slowly pull the handle out about 1/4 inch or until it is disengaged from the stem. Turn the lever on the handle away from the stop one notch then push the handle back onto stem. This setting will give the proper amount of squeeze on the valve bib washer.
    5. Now fasten the handle on with the valve handle screws.

    Note: Chrome-plated sink hole covers are available at plumbing and hardware departments of stores for covering extra holes not used on your sink.

    Keep all extra Wall or Deck Fittings included with this unit in case you change your sink type later.
